Aladdin 44 Universal Heater Wick - For Valor Convector Heaters

Aladdin 44 Universal Heater Wick - For Valor Convector Heaters

• Heater wick
• For improved operation in valor convector heaters
• Part no: 44

• Use only genuine Aladdin Wicks, as using other wicks may result in poor performance and cause problems for which Aladdin cannot be responible.

Suitable for use in the following Valor Heaters:

• 11, 12, 15, 20, 30, 32, 37, 38, 50, 207, 210
• L12, L20, L30, L32, L37, L38, L50, L60, L207, L210, L215
• Cheapheatio 420, Heatmiser 100 & 200, Module, Modulette, Valorvector, Viceroy, Vulcan etc.

To Fit:

• Remove chimney, flamespreader and gallery.
• Wind old wick up as far as possible. Extract carrier and wick.
• Place split end of the new wick over central draught tube. Line up slots on carrier with cog wheel, making sure that split is on either side of cog wheel. Ensure bottom edge of wick lining tape is not curled up or damaged.
• Ease the wick lining over the central draught tube, using fingernail or table knife.
• Push carrier down to engage cog wheel and adjust to lowest level.
• Replace gallery, flamespreader and chimney.
• Allow wick to soak for one hour before lighting.
